how to install teokit into DJI PHANTOM 4 PRO/ADV
MANUAL
Version 0.4
Version 0.4
Teokit's scope of delivery includes:
AShot sync board;
Custom flexible cable with two attached wires;
3 pin power cable for GNSS board;
2 screws for securing the AShot board;
Double-sided and insulating tape for AShot;
Teoboard distribution board with mounting nut;
MCX-MCX RF coaxial cable;
Insulating tape for Teoboard;
GNSS L1 Emlid Reach M+ board (optional)
Be extremely careful during installation process of Teokit. Please, read instruction first and make sure that you understand whole process. Mistakes during installation process might lead to failure of your drone.
If you feel that your skills and experience are not enough, please, consult with a specialist and ask for help.
Teokit manufacturer is not responsible for improper installation.
All actions you perform at your own risk and responsibility.
You will get best result by contacting professionals.
Experienced technician can easily install Teokit in 2 hours.
For those who are confident with their skills and experience – follow our instruction.
AShot sync board;
Custom flexible cable with two attached wires;
3 pin power cable for GNSS board;
2 screws for securing the AShot board;
Double-sided and insulating tape for AShot;
Teoboard distribution board with mounting nut;
MCX-MCX RF coaxial cable;
Insulating tape for Teoboard;
GNSS L1 Emlid Reach M+ board (optional)
Be extremely careful during installation process of Teokit. Please, read instruction first and make sure that you understand whole process. Mistakes during installation process might lead to failure of your drone.
If you feel that your skills and experience are not enough, please, consult with a specialist and ask for help.
Teokit manufacturer is not responsible for improper installation.
All actions you perform at your own risk and responsibility.
You will get best result by contacting professionals.
Experienced technician can easily install Teokit in 2 hours.
For those who are confident with their skills and experience – follow our instruction.
tools
You will need:
Crosshead screwdriver;
Hex screwdriver 1.5 and 2 mm;
8 mm socket wrench;
Tweezers;
Torx 7 screwdriver;
Soldering Station;
Nipper;
Drills 2 and 7 mm;
Screwdriver.
Crosshead screwdriver;
Hex screwdriver 1.5 and 2 mm;
8 mm socket wrench;
Tweezers;
Torx 7 screwdriver;
Soldering Station;
Nipper;
Drills 2 and 7 mm;
Screwdriver.
Gimbal
Put the drone upside down and unscrew 8 screws holding gimbal using a 1.5 mm hex driver.
Then carefully unscrew 2 cross screws securing flexible cable to gimbal board. Then unplug flexible cable from both DJI's 3-in-1 board and gimbal board. We will use flexible cable again in "Cable preparation" part.
Also disconnect the copter's antenna connector MMCX clip.
Remove the 2 screws securing the copter housing to its frame.
Then carefully unscrew 2 cross screws securing flexible cable to gimbal board. Then unplug flexible cable from both DJI's 3-in-1 board and gimbal board. We will use flexible cable again in "Cable preparation" part.
Also disconnect the copter's antenna connector MMCX clip.
Remove the 2 screws securing the copter housing to its frame.
HOUSING DISASSEMBLY
Detach the transparent covers from the arms.
Using a 2mm screwdriver unscrew 12 screws securing copter motors and 8 screws securing the housing.
Using a 2mm screwdriver unscrew 12 screws securing copter motors and 8 screws securing the housing.
continue of the DISASSEMBLY
Separate the bottom and top of the case by gently uncoupling the clips. If necessary, use a wooden or plastic tool to avoid damage.
Then disconnect the compass connectors.
Using a 2mm screwdriver, unscrew the 4 screws holding the copter's frame.
Then disconnect the compass connectors.
Using a 2mm screwdriver, unscrew the 4 screws holding the copter's frame.
REMOVE ANTENNAS
This are ADS-B system antennas.
Remove them so that they do not interfere with the installation of the GNSS module.
Remove them so that they do not interfere with the installation of the GNSS module.
It GETS MORE INTERESTING...
It is necessary to unsolder motors' and LEDs' wires from the DJI's regulator board (left or right side - at your discretion).
Use soldering station.
Disconnect the GPS module connector and free the upper housing from the frame.
Use soldering station.
Disconnect the GPS module connector and free the upper housing from the frame.
removing gps module
Using a crosshead screwdriver, unscrew the 3 self-tapping screws and remove the GPS module.
Put the Teokit sticker on its place, it shows where to drill the hole for the antenna connector.
Put the Teokit sticker on its place, it shows where to drill the hole for the antenna connector.
drilling
First, drill a 2 mm hole.
Then enlarge a hole with a bigger 7 mm drill.
Be gentle and try not to damage other parts of the case.
On the outside of the case, remove the DJI sticker. Remove any remaining glue with alcohol.
Then enlarge a hole with a bigger 7 mm drill.
Be gentle and try not to damage other parts of the case.
On the outside of the case, remove the DJI sticker. Remove any remaining glue with alcohol.
TEOBOARD
Install the Teoboard GNSS distribution board in the hole so that SMA connector protrudes outward.
Caution: Do not use screws that were securing DJI`s GPS module to secure Teoboard.
Secure the board with the washer and nut.
Use 8 mm socket wrench.
Caution: Do not use screws that were securing DJI`s GPS module to secure Teoboard.
Secure the board with the washer and nut.
Use 8 mm socket wrench.
Before installing Reach module into the copter, please seal the module as shown in this video.
emlid reach m+
Remove part of the septum in the front left beam using nipper and a soldering iron.
Release the Reach M+ module from its housing using a Torx 7 screwdriver.
Place the Reach M+ module in the copter beam with the antenna connector facing up.
Release the Reach M+ module from its housing using a Torx 7 screwdriver.
Place the Reach M+ module in the copter beam with the antenna connector facing up.
continue...
Remove part of the septum in the other lower part of the case by using nipper and soldering iron.
MCX connector of the RF coaxial cable connected to the Reach M+ will be placed here.
MCX connector of the RF coaxial cable connected to the Reach M+ will be placed here.
plug in
Connect Teoboard to the Reach M+ by using RF coaxial cable.
Please, be gentle during connecting MCX connectors.
Cover Teoboard with insulating tape. It is included in the scope of delivery.
Important! You need to cover Teoboard completely. Metal parts of the board should not touch the "shield".
Please, be gentle during connecting MCX connectors.
Cover Teoboard with insulating tape. It is included in the scope of delivery.
Important! You need to cover Teoboard completely. Metal parts of the board should not touch the "shield".
"shield"
Put the self-adhesive shielding layer on its place.
Guide the 4-pin Teoboard cable through the hole designed for it so it will possible to plug in to DJI's GPS module's port.
Guide the 4-pin Teoboard cable through the hole designed for it so it will possible to plug in to DJI's GPS module's port.
assembling
First you need to solder back motors' and LEDs' cables to the DJI's regulator board.
Then connect 4-pin connector of the Teoboard back to DJI's GPS module's port (from where we disconnected cable in "It gets more interesting" part).
Then screw copter's frame back to upper housing by 2mm screwdriver and 4 screw.
Be careful! Reach M+ board should not interfere with mountings of the obstacle sensors.
Then connect 4-pin connector of the Teoboard back to DJI's GPS module's port (from where we disconnected cable in "It gets more interesting" part).
Then screw copter's frame back to upper housing by 2mm screwdriver and 4 screw.
Be careful! Reach M+ board should not interfere with mountings of the obstacle sensors.
SECURING CABLES
Guide Reach M+ board's power cable to the place where AShot board will be installed and secure cable with sealant.
We recommend using Kafuter K-704B silicone rubber adhesive.
We recommend using Kafuter K-704B silicone rubber adhesive.
board insulation
Important! You need to cover GNSS board with any type of tape. Metal parts of the board should not touch the frame of the drone.
CONTINUE the ASSEMBly process...
Install the bottom housing of the copter.
Plug in the compass connectors.
After fastening the two parts of the case, plug in the antenna connectors back to the 3-in-1 board.
Secure these connectors with a metal strip with 2 screws.
Tighten the 2 screws securing the copter's housing to the frame.
Secure the copter motors with 12 screws. Connect the top of the copter to the bottom with 8 screws. Use a 2mm screwdriver.
Plug in the compass connectors.
After fastening the two parts of the case, plug in the antenna connectors back to the 3-in-1 board.
Secure these connectors with a metal strip with 2 screws.
Tighten the 2 screws securing the copter's housing to the frame.
Secure the copter motors with 12 screws. Connect the top of the copter to the bottom with 8 screws. Use a 2mm screwdriver.
ashot
Plug AShot board into DJI's 3-in-1 board.
Then plug in Reach M+ board's power cable into the 3-pin port of AShot board.
Secure AShot board to aluminum radiator with 2 screws included in the scope of delivery.
Then plug in Reach M+ board's power cable into the 3-pin port of AShot board.
Secure AShot board to aluminum radiator with 2 screws included in the scope of delivery.
gimbal
Prepare the gimbal to connect to the AShot board.
Remove the 4 screws of the upper gimbal board.
Unplug the flexible cable from rear side of gimbal board and bend down cable's right side 90 degrees as shown in the photo.
Big size photo:
https://ashot.cc/manual/image/IMG_5793.jpg
https://ashot.cc/manual/image/IMG_7615.jpg
Remove the 4 screws of the upper gimbal board.
Unplug the flexible cable from rear side of gimbal board and bend down cable's right side 90 degrees as shown in the photo.
Big size photo:
https://ashot.cc/manual/image/IMG_5793.jpg
https://ashot.cc/manual/image/IMG_7615.jpg
CABLE INSTALLATION
Connect bended right side of gimbal's flexible cable with small flexible cable came with AShot as shown in the photo.
Big size photo:
https://ashot.cc/manual/image/IMG_0329.jpg
Big size photo:
https://ashot.cc/manual/image/IMG_0329.jpg
ASSEMBLE GIMBAL
Plug flexible gimbal cable with attached AShot flexible cable into rear side of gimbal board, then put gimbal board in place and tighten it with 4 cross screws.
Plug VanavaraDigital flexible cable to the socket on gibmal board. Fix it with 2 srews.
Gimbal preparation finished.
Plug VanavaraDigital flexible cable to the socket on gibmal board. Fix it with 2 srews.
Gimbal preparation finished.
plug in
Connect the 2-wire cable to the AShot board connector.
You already connected the 3-core power cable for the Reach M + board.
You already connected the 3-core power cable for the Reach M + board.
finish
Plug flexible cable, which we earlier attached to gimbal board, into AShot's socket.
Before you fix the gimbal bowl on the copter body, carefully check the location of the cables.
Place the bowll on the bottom of the copter and tighten the 8 screws with a 1.5 mm screwdriver.
Before you fix the gimbal bowl on the copter body, carefully check the location of the cables.
Place the bowll on the bottom of the copter and tighten the 8 screws with a 1.5 mm screwdriver.
Install a spiral antenna and put the stickers.
Congratulations! Installation is complete!
Congratulations! Installation is complete!
Please see this videos:
Thank you for your interest in our kit.
